A Luneburg Lens Antenna is a spherically symmetric gradient-index focal point. An ordinary Luneburg lens’s refractive list n diminishes radially from the center to the external surface. Luneburg lens is a new generation of antennas. The centering properties of the Luneburg focal point can be accomplished through a boundless number of refractive-index arrangements.

Luneburg lens is utilized in utilizing different clusters with the ultra-broadband capability and wide seeing within the microwave radio range. RFecho Luneburg lens has the frequency range from 1.7GHz to 40GHz where Gains are 15, 20, and Return Loss is less than – 20 (dB).



Grid View
Luneburg Lens Antenna
ImageSkuFreq.Min.(GHz)Freq.Max.(GHz)Gain (dBi)Return Loss (dB)HPBW 3 dB BeamwidthPolarization

15 dBi Gain, 1.7 GHz to 2.6 GHz, 20 dB Return Loss, Luneburg Lens Antenna

OLLA-17261.72.6152030°@2.2GHzAll polarizations

15 dBi Gain, 12 GHz to 18 GHz, 20 dB Return Loss, Luneburg Lens Antenna

OLLA-1201801218152030°@15GHzAll polarizations

15 dBi Gain, 14.5 GHz to 20 GHz, 20 dB Return Loss, Luneburg Lens Antenna

OLLA-14520014.520152030°@17.5GHzAll polarizations

15 dBi Gain, 17.6 GHz to 26.7 GHz, 20 dB Return Loss, Luneburg Lens Antenna

OLLA-17626717.626.7152030°@21GHzAll polarizations

15 dBi Gain, 2.6 GHz to 4 GHz, 20 dB Return Loss, Luneburg Lens Antenna

OLLA-26402.64152030°@3.3GHzAll polarizations

15 dBi Gain, 4.6 GHz to 7 GHz, 20 dB Return Loss, Luneburg Lens Antenna

OLLA-46704.67152030°@5.8GHzAll polarizations

15 dBi Gain, 5.4 GHz to 8.2 GHz, 20 dB Return Loss, Luneburg Lens Antenna

OLLA-54825.48.2152030°@6.7GHzAll polarizations

15 dBi Gain, 6.6 GHz to 10 GHz, 20 dB Return Loss, Luneburg Lens Antenna

OLLA-661006.610152030°@8.2GHzAll polarizations

15 dBi Gain, 8.2 GHz to 12.5 GHz, 20 dB Return Loss, Luneburg Lens Antenna

OLLA-821258.212.5152030°@10GHzAll polarizations

20 dBi Gain, 2.2 GHz to 3.3 GHz, 20 dB Return Loss, Luneburg Lens Antenna

OLLA-22332.23.3202018°@2.8GHzAll polarizations

20 dBi Gain, 21.7 GHz to 33 GHz, 20 dB Return Loss, Luneburg Lens Antenna

OLLA-21733021.733202018°@26GHzAll polarizations

20 dBi Gain, 26.5 GHz to 40 GHz, 20 dB Return Loss, Luneburg Lens Antenna

OLLA-26540026.540202018°@33GHzAll polarizations

20 dBi Gain, 4 GHz to 6 GHz, 20 dB Return Loss, Luneburg Lens Antenna

OLLA-406046202018°@5GHzAll polarizations

20 dBi Gain, 9.8 GHz to 15 GHz, 20 dB Return Loss, Luneburg Lens Antenna

OLLA-981509.815202018°@12.5GHzAll polarizations

20.1 dBi Gain, 30 GHz to 40 GHz, 20 dB Return Loss, Luneburg Lens Antenna

OLLA-300400304020.1208°@30GHzAll polarizations
