Bias Tee OBT-0110-4

Showing 1–24 of 612 results

Product product-code min-frequency max-frequency insertion-loss-db-max vswr-max Action
Bias Tee OBT-810-4 OBT-810-4 0.8GHz 1.0GHz 0.5 1.20:1 Details
Bias Tee OBT-0110-4 OBT-0110-4 10MHz 1.0GHz 0.5 1.20:1 Details
Bias Tee OBT-5100-S OBT-5100-S 0.5GHz 10GHz 1.0 1.50:1 Details
Bias Tee OBT-0130-1 OBT-0130-1 10MHz 3.0GHz 1.8 1.50:1 Details
Bias Tee OBT-525-4 OBT-525-4 0.5GHz 2.5GHz 1.0 1.20:1 Details
Bias Tee OBT-0142-4 OBT-0142-4 10MHz 4.2GHz 1.2 1.20:1 Details
Bias Tee OBT-530-4 OBT-530-4 0.5GHz 3.0GHz 1.0 1.20:1 Details
Bias Tee OBT-0160-S OBT-0160-S 10MHz 6.0GHz 1.8 1.50:1 Details
Bias Tee OBT-80160-S OBT-80160-S 8.0GHz 16.0GHz 1.0 1.50:1 Details
Bias Tee OBT-03270-S OBT-03270-S 30kHz 27GHz 2.2 1.80:1 Details
Bias Tee OBT-03400-S OBT-03400-S 30kHz 40GHz 3.0 1.80:1 Details
Bias Tee OBT-03700-S OBT-03700-S 30kHz 70GHz 4.0 2.00:1 Details
Bias Tee OBT-03850-S OBT-03850-S 30kHz 85GHz 4.0 2.00:1 Details
Bias Tee OBT-100120-4 OBT-100120-4 10GHz 12GHz 1.0 1.50:1 Details
Bias Tee OBT-1124-S OBT-1124-S 100kHz 12.4GHz 1.5 1.60:1 Details
Bias Tee OBT-1180-S OBT-1180-S 100kHz 18.0GHz 2.0 1.60:1 Details
Bias Tee OBT-150-4 OBT-150-4 1GHz 5GHz 1.0 1.50:1 Details
Bias Tee OBT-1720-4 OBT-1720-4 1.7GHz 2.0GHz 0.5 1.50:1 Details
Bias Tee OBT-3180-S OBT-3180-S 300MHz 18.0GHz 1.5 1.60:1 Details
Bias Tee OBT-48-1 OBT-48-1 425MHz 800MHz 0.6 1.50:1 Details
Bias Tee OBT-50130-S OBT-50130-S 5GHz 12GHz 0.8 1.50:1 Details
Product product-code min-freq-ghz max-freq-ghz insertion-loss-db-max directivity-db Action
Directional Coupler ODC60265-20 ODC60265-20 6.0 26.5 0.7 15.0 Details
Directional Coupler ODC60400-10 ODC60400-10 6.0 40 1.6 12.0 Details
Directional Coupler ODC60265-30 ODC60265-30 6.0 26.5 0.8 13.0 Details
Directional Coupler ODC60180-10 ODC60180-10 6.0 18 1.0 15.0 Details
Directional Coupler ODC580-20 ODC580-20 0.5 8 0.8 20.0 Details
Directional Coupler ODC580-30 ODC580-30 0.5 8 0.7 18.0 Details
Directional Coupler ODC580-10 ODC580-10 0.5 8 1.2 18.0 Details
Directional Coupler ODC5400-10 ODC5400-10 0.5 40 3.0 11.0 Details
Directional Coupler ODC20400-10 ODC20400-10 2.0 40 2.1 10.0 Details
Directional Coupler ODC20400-13 ODC20400-13 2.0 40 1.9 10.0 Details
Directional Coupler ODC20400-16 ODC20400-16 2.0 40 1.6 10.0 Details
Directional Coupler ODC265400-10 ODC265400-10 26.5 40 1.5 12.0 Details
Directional Coupler ODC4200-10 ODC4200-10 0.4 20 2.2 13.0 Details
Directional Coupler ODC5200-10 ODC5200-10 0.5 20 1.7 15.0 Details
Directional Coupler ODC5265-10 ODC5265-10 0.5 26.5 2.2 14.0 Details
Directional Coupler ODC5265-16 ODC5265-16 0.5 26.5 1.7 14.0 Details
Directional Coupler ODC5265-20 ODC5265-20 0.5 26.5 1.7 14.0 Details
Directional Coupler ODC5265-30 ODC5265-30 0.5 26.5 1.9 15.0 Details
Directional Coupler ODC100400-20 ODC100400-20 10.0 40 1.9 12.0 Details
Directional Coupler ODC20265-10 ODC20265-10 2.0 26.5 5.0 13.0 Details
Directional Coupler ODC10200-10 ODC10200-10 1.0 20 1.4 15.0 Details
Directional Coupler ODC20265-16 ODC20265-16 2.0 26.5 1.0 13.0 Details
Directional Coupler ODC10265-16 ODC10265-16 1.0 26.5 1.3 12.0 Details
Directional Coupler ODC20265-20 ODC20265-20 2.0 26.5 2.0 14.0 Details
Directional Coupler ODC10265-20 ODC10265-20 1.0 26.5 1.2 14.0 Details
Directional Coupler ODC10400-10 ODC10400-10 1.0 40 3.0 10.0 Details
Directional Coupler ODC10400-13 ODC10400-13 1.0 40 2.5 10.0 Details
Directional Coupler ODC10400-20 ODC10400-20 1.0 40 1.9 10.0 Details
Directional Coupler ODC180265-20 ODC180265-20 18.0 26.5 0.8 14.0 Details
Directional Coupler ODC180265-30 ODC180265-30 18.0 26.5 0.7 14.0 Details
Directional Coupler ODC180400-10 ODC180400-10 18.0 40 1.5 12.0 Details
Directional Coupler ODC180400-20 ODC180400-20 18.0 40 1.2 13.0 Details
Directional Coupler ODC180400-30 ODC180400-30 18.0 40 1.0 12.0 Details
Directional Coupler ODC20180-10 ODC20180-10 2.0 18 1.3 15.0 Details
Directional Coupler ODC20180-16 ODC20180-16 2.0 18 0.8 16.0 Details
Directional Coupler ODC100400-10 ODC100400-10 10.0 40 3.0 10.0 Details
Directional Coupler ODC20180-20 ODC20180-20 2.0 18 0.8 16.0 Details
Directional Coupler ODC20200-10 ODC20200-10 2.0 26.5 5.0 13.0 Details
Product product-code min-freq-ghz max-freq-ghz insertion-loss-db isolation-db vswr Action
Ferrite Devices OISF-42-S OISF-42-S 18.0 26.5 1.20 30 NA Details
Ferrite Devices OISF-28-S OISF-28-S 26.5 40.0 1.20 30 NA Details
Ferrite Devices OISC-90-H OISC-90-H 8.0 12.4 0.25 21 1.15:1 Details
Ferrite Devices OISC-760780-15-35-12 OISC-760780-15-35-12 8.2 12.4 0.45 25 NA Details
Ferrite Devices OISC-610640-10-16-15 OISC-610640-10-16-15 61.0 64.0 1.00 16 1.4:1 Details
Ferrite Devices OISC-640660-07-18-15 OISC-640660-07-18-15 64.0 66.0 0.70 18 1.3:1 Details
Ferrite Devices OISC-62-H OISC-62-H 12.4 18.0 0.25 20 1.15:1 Details
Ferrite Devices OISC-42 OISC-42 18.0 26.5 0.40 20 NA Details
Ferrite Devices OISC-28-H OISC-28-H 26.5 40.0 0.40 15 NA Details
Ferrite Devices OIS-90-H OIS-90-H 8.2 12.4 0.25 21 1.15:1 Details
Ferrite Devices OIS-62-H OIS-62-H 12.4 18.0 0.25 21 1.15:1 Details
Ferrite Devices OISC-590610-10-16-15 OISC-590610-10-16-15 59.0 61.0 1.00 16 1.4:1 Details
Ferrite Devices OISC-380400-04-20-28 OISC-380400-04-20-28 38.0 40.0 0.30 20 NA Details
Ferrite Devices OISC-340360-03-20-28 OISC-340360-03-20-28 34.0 36.0 0.30 20 1.4:1 Details
Ferrite Devices OIS-710760-08-18-12 OIS-710760-08-18-12 71.0 76.0 0.80 18 NA Details
Ferrite Devices OIS-640660-08-18-15 OIS-640660-08-18-15 64.0 66.0 0.80 18 1.4:1 Details
Ferrite Devices OISC-540560-07-18-15 OISC-540560-07-18-15 54.0 56.0 0.70 18 1.3:1 Details
Ferrite Devices OIS-180270-15-15-KFKF-I OIS-180270-15-15-KFKF-I 18.0 26.5 1.50 15 NA Details
Ferrite Devices OIS-370400-05-18-28 OIS-370400-05-18-28 37.0 40.0 0.50 18 1.35:1 Details
Ferrite Devices OIS-180210-04-18-51 OIS-180210-04-18-51 18.0 21.0 0.40 18 1.4:1 Details
Ferrite Devices OIS-340360-05-18-28 OIS-340360-05-18-28 33.6 36.4 0.50 18 1.35:1 Details
Ferrite Devices OIS-170190-02-20-42 OIS-170190-02-20-42 17.2 19.4 0.20 20 NA Details
Ferrite Devices OIS-340360-03-20-28 OIS-340360-03-20-28 34.0 36.0 0.30 20 1.4:1 Details
Ferrite Devices OIS-34-H OIS-34-H 22.0 33.0 0.45 19 1.25:1 Details
Ferrite Devices OIS-290310-03-20-28 OIS-290310-03-20-28 29.0 31.0 0.30 20 1.4:1 Details
Ferrite Devices OIS-590610-10-16-15 OIS-590610-10-16-15 59.0 61.0 1.00 16 1.4:1 Details
Ferrite Devices OIS-270400-16-14-KMKM-I OIS-270400-16-14-KMKM-I 26.5 40.0 1.60 14 NA Details
Ferrite Devices OIS-270400-16-14-KMKF-I OIS-270400-16-14-KMKF-I 26.5 40.0 1.60 14 NA Details
Ferrite Devices OIS-270400-16-14-KFKM-I OIS-270400-16-14-KFKM-I 26.5 40.0 1.60 14 NA Details
Ferrite Devices OIS-270400-16-14-KFKF-I OIS-270400-16-14-KFKF-I 26.5 40.0 1.60 14 NA Details
Ferrite Devices OIS-270400-16-14-KFKF-C OIS-270400-16-14-KFKF-C 26.5 40.0 1.60 14 1.6:1 Details
Ferrite Devices OIS-180270-15-15-SFSF-I OIS-180270-15-15-SFSF-I 18.0 26.5 1.50 15 1.5:1 Details
Ferrite Devices OIS-540560-10-16-15 OIS-540560-10-16-15 54.0 56.0 1.00 16 1.4:1 Details
Ferrite Devices OIS-460480-05-18-22 OIS-460480-05-18-22 46.0 48.0 0.50 18 NA Details
Ferrite Devices OIS-430460-05-18-22 OIS-430460-05-18-22 43.0 46.0 0.50 18 1.3:1 Details
Ferrite Devices OIS-42 OIS-42 18.0 26.5 0.30 20 NA Details
Ferrite Devices OIS-400440-07-18-2224F-S OIS-400440-07-18-2224F-S 40.0 44.0 0.70 18 1.3:1 Details
Product product-code min-passband-freq-ghz max-passband-freq-ghz insertion-loss-db rejection-db max-rejection-freq-low-side-ghz min-rejection-freq-high-side-ghz waveguide-size Action
Filter Bandpass OWBP-93209520-10 OWBP-93209520-10 93.2 95.2 2.5 40 91 98.5 WR-10 Details
Filter Bandpass OWBP-980010200-10 OWBP-980010200-10 98 102 2 40 95 105 WR-10 Details
Filter Bandpass OWBP-92509550-10 OWBP-92509550-10 92.5 95.5 2.5 20 91.5 97 WR-10 Details
Filter Bandpass OWBP-92009600-10 OWBP-92009600-10 92 96 1 35-40 90 98 WR-10 Details
Filter Bandpass OWBP-76008100-12 OWBP-76008100-12 76 81 2.0-3.0 40 73 84 WR-12 Details
Filter Bandpass OWBP-71007600-10 OWBP-71007600-10 71 76 2.0-2.5 40-50 67 81 WR-10 Details
Filter Bandpass OWBP-61706270-15 OWBP-61706270-15 61.7 62.7 2 40 60 65 WR-15 Details
Filter Bandpass OWBP-920010000-10 OWBP-920010000-10 92 110 2.5 50 88 104 WR-10 Details
Filter Bandpass OWBP-82508700-12 OWBP-82508700-12 82.5 87 2.5-3.0 40 80 90 WR-12 Details
Filter Bandpass OWBP-63006700-12 OWBP-63006700-12 63 67 2.0 - 2.5 40 57 73 WR-12 Details
Filter Bandpass OWBP-73007400-12 OWBP-73007400-12 73 74 2.0-2.5 30 70 76.5 WR-12 Details
Filter Bandpass OWBP-71007600-12 OWBP-71007600-12 71 76 2.0-2.5 40-50 67 81 WR-12 Details
Filter Bandpass OWBP-73007600-12 OWBP-73007600-12 73 76 1.3-2.5 40 67 82 WR-12 Details
Filter Bandpass OWBP-70009000-12 OWBP-70009000-12 70 90 2.0-3.0 40 60 93.3 WR-12 Details
Filter Bandpass OWBP-61606360-15 OWBP-61606360-15 61.6 63.6 2.5 50 56.6 67.6 WR-15 Details
Filter Bandpass OWBP-90009800-10 OWBP-90009800-10 90 98 2.5 25 88 102 WR-10 Details
Filter Bandpass OWBP-81008600-12 OWBP-81008600-12 81 86 2.0-2.5 40-50 68 90 WR-12 Details
Filter Bandpass OWBP-76007700-12 OWBP-76007700-12 76 77 2 50 74.5 78.5 WR-12 Details
Filter Bandpass OWBP-63806580-15 OWBP-63806580-15 63.8 65.8 2.5 50 58.8 70.8 WR-15 Details
Filter Bandpass OWBP-75007800-12 OWBP-75007800-12 75 78 1.5-2.5 50 71 82 WR-12 Details
Filter Bandpass OWBP-82508550-10 OWBP-82508550-10 82.5 85.5 2.5 35-40 79 93.5 WR-10 Details
Filter Bandpass OWBP-74007600-12 OWBP-74007600-12 74 76 1.5-2.5 40 70 80 WR-12 Details
Filter Bandpass OWBP-81008600-10 OWBP-81008600-10 81 86 2.0-2.5 40-50 78 88 WR-10 Details
Filter Bandpass OWBP-81008700-12 OWBP-81008700-12 81 87 2.0 - 4.0 @ 81 GHz 30 78 90 WR-12 Details
Filter Bandpass OWBP-58606340-15 OWBP-58606340-15 58.6 63.4 2 50 56 68 WR-15 Details
Filter Bandpass OWBP-59006100-15 OWBP-59006100-15 59 61 2.5 25 58 62 WR-15 Details
Filter Bandpass OWBP-57325932-15 OWBP-57325932-15 57.3 59.3 2.5 50 55.3 61.3 WR-15 Details
Filter Bandpass OWBP-59006500-15 OWBP-59006500-15 59 65 2.5 40 57.5 67.5 WR-15 Details
Filter Bandpass OWBP-59506150-15 OWBP-59506150-15 59.5 61.5 2.5 50 54.5 66.5 WR-15 Details
Filter Bandpass OWBP-60006200-15 OWBP-60006200-15 60 62 2.5 30 59 64 WR-15 Details
Filter Bandpass OWBP-61006600-15 OWBP-61006600-15 61 66 2 40 59 69 WR-15 Details
Filter Bandpass OWBP-61006400-15 OWBP-61006400-15 61 64 2.5 40 58 67 WR-15 Details
Filter Bandpass OWBP-57506250-15 OWBP-57506250-15 57.5 62.5 2 25 55 67 WR-15 Details
Filter Bandpass OWBP-47005900-15 OWBP-47005900-15 47 59 2 50 44 63 WR-15 Details
Filter Bandpass OWBP-36006000-19 OWBP-36006000-19 10 15 1.5 40 29 66 WR-19 Details
Filter Bandpass OWBP-51505450-15 OWBP-51505450-15 51.5 54.5 1.0-2.0 40 44 60 WR-15 Details
Filter Bandpass OWBP-35263626-28 OWBP-35263626-28 35.3 36.3 1.2 40 33.9 38 WR-28 Details
Filter Bandpass OWBP-30005000-22 OWBP-30005000-22 30 50 1.5 40 25 56 WR-22 Details
Filter Bandpass OWBP-47005700-15 OWBP-47005700-15 47 57 2.5 40 44 62 WR-15 Details
Filter Bandpass OWBP-51005500-15 OWBP-51005500-15 51 55 1.5-2.5 30 47 59 WR-15 Details
Filter Bandpass OWBP-49755025-15 OWBP-49755025-15 49.8 50.3 2.5-3 30 49 51 WR-15 Details
Filter Bandpass OWBP-50006700-15 OWBP-50006700-15 50 67 2.0-3.0 40 46 73 WR-15 Details
Filter Bandpass OWBP-54505650-15 OWBP-54505650-15 54.5 56.5 2.5 50 53 57 WR-15 Details
Filter Bandpass OWBP-22003800-28 OWBP-22003800-28 22 38 2 50 20 41 WR-28 Details
Filter Bandpass OWBP-26004000-28 OWBP-26004000-28 26 40 1.2-2.0 60 18 48 WR-28 Details
Filter Bandpass OWBP-1050014000-08 OWBP-1050014000-08 105 140 2.5 40 94 145 WR-08 Details
Filter Bandpass OWBP-1250015000-06 OWBP-1250015000-06 125 150 4.5 40 100 163 WR-06 Details
Filter Bandpass OWBP-1090014000-08 OWBP-1090014000-08 109 140 2.5 40 94 145 WR-08 Details
Filter Bandpass OWBP-34006700-19 OWBP-34006700-19 34 67 1.5 20-40 30 18 WR-19 Details
Filter Bandpass OWBP-30004500-22 OWBP-30004500-22 30 45 2 40 28 47 WR-22 Details
Filter Bandpass OWBP-50007500-15 OWBP-50007500-15 50 75 2.0-3.0 40 44 80 WR-15 Details
Filter Bandpass OWBP-55006700-15 OWBP-55006700-15 55 67 2.0-2.5 40 51 71 WR-15 Details
Filter Bandpass OWBP-33003700-28 OWBP-33003700-28 33 37 1.5 40 31 39 WR-28 Details
Product product-code min-passband-freq-ghz insertion-loss-db rejection-db min-rejection-freq-low-side-ghz min-rejection-freq-high-side-ghz waveguide-size Action
Filter Highpass OWBP-6300-12 OWBP-6300-12 63 0.8 40 DC 59 WR-12 Details
Filter Highpass OWBP-6000-12 OWBP-6000-12 60 1.0 40 DC 55 WR-12 Details
Filter Highpass OWBP-1040020000-08 OWBP-1040020000-08 104 2.5 40 DC 100 WR-08 Details
Filter Highpass OWBP-9200-10 OWBP-9200-10 92 1.0 40 DC 86 WR-10 Details
Filter Highpass OWBP-9000-10 OWBP-9000-10 90 1.0 40 DC 84 WR-10 Details
Filter Highpass OWBP-8600-10 OWBP-8600-10 86 1.0 40 DC 82 WR-10 Details
Filter Highpass OWBP-8400-10 OWBP-8400-10 84 0.9 40 DC 80 WR-10 Details
Filter Highpass OWBP-8200-10 OWBP-8200-10 82 1.0 40 DC 80 WR-10 Details
Filter Highpass OWBP-8100-12 OWBP-8100-12 81 1.0 40 DC 77 WR-12 Details
Filter Highpass OWBP-7500-15 OWBP-7500-15 75 1.0 40 DC 71 WR-15 Details
Filter Highpass OWBP-7500-10 OWBP-7500-10 75 1.0 40 DC 70 WR-10 Details
Filter Highpass OWBP-7100-12 OWBP-7100-12 71 0.8 40 DC 67 WR-12 Details
Filter Highpass OWBP-5000-15 OWBP-5000-15 50 1.0 40 DC 46 WR-15 Details
Filter Highpass OWBP-7000-12 OWBP-7000-12 70 0.5 40 DC 66 WR-12 Details
Filter Highpass OWBP-6700-12 OWBP-6700-12 67 1.0 40 DC 65 WR-12 Details
Filter Highpass OWBP-6300-15 OWBP-6300-15 63 1.0 40 DC 57 WR-15 Details
Product product-code min-passband-freq-ghz max-passband-freq-ghz insertion-loss-db rejection-db max-rejection-freq-low-side-ghz min-rejection-freq-high-side-ghz waveguide-size Action
Filter Lowpass OWBP-26504000-28 OWBP-26504000-28 26.5 40 1.0 60 21 40 WR-28 Details
Filter Lowpass OWBP-50007500-15 OWBP-50007500-15 50 75 1.5 40 NA 79 WR-15 Details
Filter Lowpass OWBP-50007500-12 OWBP-50007500-12 50 75 2.2 60 48 79 WR-12 Details
Filter Lowpass OWBP-10001500-75 OWBP-10001500-75 10 15 1.0 40 8 18 WR-75 Details
Filter Lowpass OWBP-20002600-28 OWBP-20002600-28 26 60 1.0 50 20 90 WR-28 Details
Filter Lowpass OWBP-15002200-51 OWBP-15002200-51 15 22 1.0 40 12 25 WR-51 Details
Filter Lowpass OWBP-50008400-12 OWBP-50008400-12 50 84 2.2 40 48 87 WR-12 Details
Filter Lowpass OWBP-620011000-10 OWBP-620011000-10 62 110 1.6-2.0 40-50 56 120 WR-10 Details
Filter Lowpass OWBP-62009000-10 OWBP-62009000-10 62 90 3.5 80 58 92 WR-10 Details
Product product-code min-freq-ghz max-freq-ghz angle orientation bend-radius-length waveguide-size Action
Waveguide Bends and Twists OWB-12-6090-5 OWB-12-6090-5 60 90 90 Degrees Twist 1 WR-12 Details
Waveguide Bends and Twists OWB-12-6090-6 OWB-12-6090-6 60 90 90 Degrees Twist 1.3 WR-12 Details
Waveguide Bends and Twists OWB-12-6090-7 OWB-12-6090-7 60 90 45 Degrees E-Plane Bend 0.8 WR-12 Details
Waveguide Bends and Twists OWB-12-6090-8 OWB-12-6090-8 60 90 45 Degrees Left-Handed Twist 1.3 WR-12 Details
Waveguide Bends and Twists OWB-12-6090-9 OWB-12-6090-9 60 90 45 Degrees Right-Handed Twist 1 WR-12 Details
Waveguide Bends and Twists OWB-12-6090-10 OWB-12-6090-10 60 90 45 Degrees Left-Handed Twist 1 WR-12 Details
Waveguide Bends and Twists OWB-15-5075-1 OWB-15-5075-1 50 75 90 Degrees E-Plane Bend 1 WR-15 Details
Waveguide Bends and Twists OWB-15-5075-2 OWB-15-5075-2 50 75 90 Degrees E-Plane Bend 0.8 WR-15 Details
Waveguide Bends and Twists OWB-06-110170-4 OWB-06-110170-4 110 170 45 Degrees Left-Handed Twist 1.3 WR-06 Details
Waveguide Bends and Twists OWB-12-6090-4 OWB-12-6090-4 60 90 90 Degrees H-Plane Bend 0.8 WR-12 Details
Waveguide Bends and Twists OWB-06-110170-2 OWB-06-110170-2 110 170 90 Degrees H-Plane Bend 0.8 WR-06 Details
Waveguide Bends and Twists OWB-10-75110-1 OWB-10-75110-1 75 110 90 Degrees E-Plane Bend 0.8 WR-10 Details
Waveguide Bends and Twists OWB-08-90140-4 OWB-08-90140-4 90 140 45 Degrees Left-Handed Twist 1.3 WR-08 Details
Waveguide Bends and Twists OWB-08-90140-1 OWB-08-90140-1 90 140 90 Degrees E-Plane Bend 0.8 WR-08 Details
Waveguide Bends and Twists OWB-08-90140-5 OWB-08-90140-5 90 140 45 Degrees Left-Handed Twist 1 WR-08 Details
Waveguide Bends and Twists OWB-06-110170-5 OWB-06-110170-5 110 170 45 Degrees Left-Handed Twist 1 WR-06 Details
Waveguide Bends and Twists OWB-08-90140-3 OWB-08-90140-3 90 140 90 Degrees Twist 1.3 WR-08 Details
Waveguide Bends and Twists OWB-10-75110-2 OWB-10-75110-2 75 110 90 Degrees H-Plane Bend 1 WR-10 Details
Waveguide Bends and Twists OWB-08-90140-2 OWB-08-90140-2 90 140 90 Degrees H-Plane Bend 0.8 WR-08 Details
Waveguide Bends and Twists OWB-10-75110-3 OWB-10-75110-3 75 110 90 Degrees H-Plane Bend 0.8 WR-10 Details
Waveguide Bends and Twists OWB-06-110170-3 OWB-06-110170-3 110 170 90 Degrees Twist 1.3 WR-06 Details
Waveguide Bends and Twists OWB-10-75110-4 OWB-10-75110-4 75 110 90 Degrees Twist 1.3 WR-10 Details
Waveguide Bends and Twists OWB-10-75110-5 OWB-10-75110-5 75 110 45 Degrees Left-Handed Twist 1.3 WR-10 Details
Waveguide Bends and Twists OWB-10-75110-6 OWB-10-75110-6 75 110 45 Degrees Left-Handed Twist 1 WR-10 Details
Waveguide Bends and Twists OWB-12-6090-1 OWB-12-6090-1 60 90 90 Degrees E-Plane Bend 1 WR-12 Details
Waveguide Bends and Twists OWB-12-6090-2 OWB-12-6090-2 60 90 90 Degrees E-Plane Bend 0.8 WR-12 Details
Waveguide Bends and Twists OWB-06-110170-1 OWB-06-110170-1 110 170 90 Degrees E-Plane Bend 0.8 WR-06 Details
Waveguide Bends and Twists OWB-12-6090-3 OWB-12-6090-3 60 90 90 Degrees H-Plane Bend 1 WR-12 Details
Waveguide Bends and Twists OWB-42-2233-4 OWB-42-2233-4 22 33 90 Degrees Twist 2 WR-42 Details
Waveguide Bends and Twists OWB-42-1827-3 OWB-42-1827-3 18 26.5 45 Degrees Left-Handed Twist 2.5 WR-42 Details
Waveguide Bends and Twists OWB-42-1827-2 OWB-42-1827-2 18 26.5 90 Degrees Twist 2.5 WR-42 Details
Waveguide Bends and Twists OWB-28-2740-6 OWB-28-2740-6 26.5 40 90 Degrees H-Plane Bend 1 WR-28 Details
Waveguide Bends and Twists OWB-34-2233-2 OWB-34-2233-2 22 33 90 Degrees H-Plane Bend 1 WR-34 Details
Waveguide Bends and Twists OWB-34-2233-1 OWB-34-2233-1 22 33 90 Degrees E-Plane Bend 1 WR-34 Details
Waveguide Bends and Twists OWB-28-2740-9 OWB-28-2740-9 26.5 40 45 Degrees Right-Handed Twist 2 WR-28 Details
Waveguide Bends and Twists OWB-34-2233-3 OWB-34-2233-3 22 33 45 Degrees Left-Handed Twist 2 WR-34 Details
Waveguide Bends and Twists OWB-42-1827-1 OWB-42-1827-1 18 26.5 90 Degrees E-Plane Bend 1.3 WR-42 Details
Waveguide Bends and Twists OWB-15-5075-5 OWB-15-5075-5 50 75 90 Degrees Twist 1.3 WR-15 Details
Waveguide Bends and Twists OWB-28-2740-3 OWB-28-2740-3 26.5 40 90 Degrees H-Plane Bend 1.3 WR-28 Details
Waveguide Bends and Twists OWB-19-4060-2 OWB-19-4060-2 40 60 90 Degrees H-Plane Bend 1 WR-19 Details
Waveguide Bends and Twists OWB-15-5075-6 OWB-15-5075-6 50 75 45 Degrees Left-Handed Twist 1.3 WR-15 Details
Waveguide Bends and Twists OWB-15-5075-7 OWB-15-5075-7 50 75 45 Degrees Left-Handed Twist 1 WR-15 Details
Waveguide Bends and Twists OWB-19-4060-1 OWB-19-4060-1 40 60 90 Degrees E-Plane Bend 1 WR-19 Details
Waveguide Bends and Twists OWB-22-3350-3 OWB-22-3350-3 33 50 90 Degrees Twist 2 WR-22 Details
Waveguide Bends and Twists OWB-19-4060-3 OWB-19-4060-3 40 60 90 Degrees Twist 1.5 WR-19 Details
Waveguide Bends and Twists OWB-28-2740-4 OWB-28-2740-4 26.5 40 90 Degrees E-Plane Bend 1.3 WR-28 Details
Waveguide Bends and Twists OWB-28-2740-5 OWB-28-2740-5 26.5 40 90 Degrees Twist 2 WR-28 Details
Waveguide Bends and Twists OWB-15-5075-4 OWB-15-5075-4 50 75 90 Degrees H-Plane Bend 0.8 WR-15 Details
Waveguide Bends and Twists OWB-15-5075-3 OWB-15-5075-3 50 75 90 Degrees H-Plane Bend 1 WR-15 Details
Waveguide Bends and Twists OWB-19-4060-5 OWB-19-4060-5 40 60 45 Degrees Left-Handed Twist 1 WR-19 Details
Waveguide Bends and Twists OWB-19-4060-4 OWB-19-4060-4 40 60 45 Degrees Left-Handed Twist 1.5 WR-19 Details
Waveguide Bends and Twists OWB-22-3350-2 OWB-22-3350-2 33 50 90 Degrees H-Plane Bend 1 WR-22 Details
Waveguide Bends and Twists OWB-22-3350-5 OWB-22-3350-5 33 50 45 Degrees Left-Handed Twist 1 WR-22 Details
Waveguide Bends and Twists OWB-28-2740-1 OWB-28-2740-1 26.5 40 90 Degrees E-Plane Bend 1 WR-28 Details
Waveguide Bends and Twists OWB-28-2740-2 OWB-28-2740-2 26.5 40 90 Degrees Twist 1 WR-28 Details
Waveguide Bends and Twists OWB-22-3350-4 OWB-22-3350-4 33 50 45 Degrees Left-Handed Twist 2 WR-22 Details
Waveguide Bends and Twists OWB-22-3350-1 OWB-22-3350-1 33 50 90 Degrees E-Plane Bend 1 WR-22 Details
Product product-code min-freq-ghz max-freq-ghz insertion-length waveguide-size Action
Waveguide Bulkhead Adapters OWW-2805 OWW-2805 26.5 40.0 0.5" WR-28 Details
Waveguide Bulkhead Adapters OWW-2815 OWW-2815 26.5 40.0 1.5" WR-28 Details
Waveguide Bulkhead Adapters OWW-1005 OWW-1005 75.0 110.0 0.5" WR-10 Details
Waveguide Bulkhead Adapters OWW-3405 OWW-3405 22.0 33.0 0.5" WR-34 Details
Waveguide Bulkhead Adapters OWW-1505 OWW-1505 50.0 75.0 0.5" WR-15 Details
Waveguide Bulkhead Adapters OWW-0805 OWW-0805 90.0 140.0 0.5" WR-08 Details
Waveguide Bulkhead Adapters OWW-0505 OWW-0505 140.0 220.0 0.5" WR-05 Details
Waveguide Bulkhead Adapters OWW-0605 OWW-0605 110.0 170.0 0.5" WR-06 Details
Waveguide Bulkhead Adapters OWW-0305 OWW-0305 220.0 330.0 0.5" WR-03 Details
Waveguide Bulkhead Adapters OWW-2205-599 OWW-2205-599 33.0 50.0 0.5" WR-22 Details
Waveguide Bulkhead Adapters OWW-2205 OWW-2205 33.0 50.0 0.5" WR-22 Details
Waveguide Bulkhead Adapters OWW-1205 OWW-1205 60.0 90.0 0.5" WR-12 Details
Waveguide Bulkhead Adapters OWW-1905 OWW-1905 40.0 60.0 0.5" WR-19 Details
Waveguide Bulkhead Adapters OWW-3410 OWW-3410 22.0 33.0 1.0" WR-34 Details
Waveguide Bulkhead Adapters OWW-4205 OWW-4205 18.0 26.5 0.5" WR-42 Details
Product product-code min-freq-ghz max-freq-ghz coupling-level-db directivity-db way Action
Waveguide Crossguide Coupler OWX-510590-20 OWX-510590-20 51.0 59.0 20.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-690900-15-1 OWX-690900-15-1 69.0 90.0 15.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-690900-15-2 OWX-690900-15-2 69.0 90.0 15.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-690900-20 OWX-690900-20 69.0 90.0 20.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-690900-30 OWX-690900-30 69.0 90.0 30.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-690900-40 OWX-690900-40 69.0 90.0 40.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-710860-20 OWX-710860-20 71.0 86.0 20.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-7501100-20-1 OWX-7501100-20-1 75.0 110.0 20.0 20.0 16 Details
Waveguide Crossguide Coupler OWX-7501100-20-2 OWX-7501100-20-2 75.0 110.0 20.0 20.0 16 Details
Waveguide Crossguide Coupler OWX-920960-20 OWX-920960-20 92.0 96.0 20.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-10001050-15 OWX-10001050-15 100.0 105.0 15.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-400600-40 OWX-400600-40 40.0 60.0 40.0 20.0 16 Details
Waveguide Crossguide Coupler OWX-270290-40 OWX-270290-40 27.0 29.0 40.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-500750-20 OWX-500750-20 50.0 75.0 20.0 20.0 16 Details
Waveguide Crossguide Coupler OWX-310390-15 OWX-310390-15 31.0 39.0 15.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-500750-30 OWX-500750-30 50.0 75.0 30.0 20.0 16 Details
Waveguide Crossguide Coupler OWX-310390-20-1 OWX-310390-20-1 31.0 39.0 20.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-500750-40 OWX-500750-40 50.0 75.0 40.0 20.0 16 Details
Waveguide Crossguide Coupler OWX-310390-20-2 OWX-310390-20-2 31.0 39.0 20.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-310390-30 OWX-310390-30 31.0 39.0 30.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-310390-40 OWX-310390-40 31.0 39.0 40.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-350450-20 OWX-350450-20 35.0 45.0 20.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-350450-30 OWX-350450-30 35.0 45.0 30.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-350450-40 OWX-350450-40 35.0 45.0 40.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-400480-20 OWX-400480-20 40.0 48.0 20.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-400480-30 OWX-400480-30 40.0 48.0 30.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-400480-40 OWX-400480-40 40.0 48.0 40.0 15.0 16 Details
Waveguide Crossguide Coupler OWX-400600-10 OWX-400600-10 40.0 60.0 10.0 20.0 16 Details
Waveguide Crossguide Coupler OWX-400600-20 OWX-400600-20 40.0 60.0 20.0 20.0 16 Details
Waveguide Crossguide Coupler OWX-400600-30 OWX-400600-30 40.0 60.0 30.0 20.0 16 Details
Product product-code min-freq-ghz max-freq-ghz insertion-loss-db coupling-db directivity-db vswr waveguide-size Action
Waveguide Directional Couplers OWD-3040H-28-BB OWD-3040H-28-BB 26.5 40 0.5 30 35 1.1:1 WR-28 WG Details
Waveguide Directional Couplers OWD-4040H-19-BB OWD-4040H-19-BB 40 60 0.7 40 35 1.1:1 WR-19 WG Details
Waveguide Directional Couplers OWD-4040H-22-BB OWD-4040H-22-BB 33 50 0.6 40 35 1.10:1 WR-22 WG Details
Waveguide Directional Couplers OWD-4040H-28-BB OWD-4040H-28-BB 26.5 40 0.5 40 35 1.1:1 WR-28 WG Details
Waveguide Directional Couplers OWD-1040H-28-BB OWD-1040H-28-BB 26.5 40 0.5 10 35 1.1:1 WR-28 WG Details
Waveguide Directional Couplers OWD-1040H-42-SB OWD-1040H-42-SB 18 26.5 0.5 10 30 1.1:1 WR-42 WG Details
Waveguide Directional Couplers OWD-1140H-101F-BB-E OWD-1140H-101F-BB-E 75 110 3 11 30-40 NA Details
Waveguide Directional Couplers OWD-2040H-19-BB OWD-2040H-19-BB 40 60 0.7 20 35 1.1:1 WR-19 WG Details
Waveguide Directional Couplers OWD-0340H-19-BB OWD-0340H-19-BB 40 60 0.7 3 35 1.1:1 WR-19 WG Details
Waveguide Directional Couplers OWD-2040H-22-BB OWD-2040H-22-BB 33 50 0.6 20 35 1.10:1 WR-22 WG Details
Waveguide Directional Couplers OWD-0340H-22-BB OWD-0340H-22-BB 33 50 0.6 3 35 1.10:1 WR-22 WG Details
Waveguide Directional Couplers OWD-2040H-28-BB OWD-2040H-28-BB 26.5 40 0.5 20 35 1.10:1 WR-28 WG Details
Waveguide Directional Couplers OWD-0340H-28-BB OWD-0340H-28-BB 26.5 40 0.5 3 35 1.1:1 WR-28 WG Details
Waveguide Directional Couplers OWD-3040H-19-BB OWD-3040H-19-BB 40 60 0.7 30 35 1.1:1 WR-19 WG Details
Waveguide Directional Couplers OWD-0340H-42-SB OWD-0340H-42-SB 18 26.5 0.5 3 30 1.1:1 WR-42 WG Details
Waveguide Directional Couplers OWD-3040H-22-BB OWD-3040H-22-BB 33 50 0.6 30 35 1.10:1 WR-22 WG Details
Waveguide Directional Couplers OWD-0640H-12-DB OWD-0640H-12-DB 60 90 1.5 6 30-40 1.1:1 WR-12 WG Details
Waveguide Directional Couplers OWD-0640H-19-BB OWD-0640H-19-BB 40 60 0.7 6 35 1.1:1 WR-19 WG Details
Waveguide Directional Couplers OWD-0640H-22-BB OWD-0640H-22-BB 33 50 0.6 6 35 1.10:1 WR-22 WG Details
Waveguide Directional Couplers OWD-0640H-28-BB OWD-0640H-28-BB 26.5 40 0.5 6 35 1.1:1 WR-28 WG Details
Waveguide Directional Couplers OWD-0640H-42-SB OWD-0640H-42-SB 18 26.5 0.5 6 30 1.1:1 WR-42 WG Details
Waveguide Directional Couplers OWD-0740H-101F-BB-E OWD-0740H-101F-BB-E 75 110 3 7 30-40 NA Details
Waveguide Directional Couplers OWD-1040H-19-BB OWD-1040H-19-BB 40 60 0.7 10 35 1.1:1 WR-19 WG Details
Waveguide Directional Couplers OWD-1040H-22-BB OWD-1040H-22-BB 33 50 0.6 10 35 1.10:1 WR-22 WG Details
Waveguide Directional Couplers OWD-4040H-19-SB OWD-4040H-19-SB 40 60 0.7 40 35 1.1:1 WR-19 WG Details
Waveguide Directional Couplers OWD-4040H-22-SB OWD-4040H-22-SB 33 50 0.6 40 35 1.10:1 WR-22 WG Details
Waveguide Directional Couplers OWD-4040H-12-BB OWD-4040H-12-BB 75 110 1.0 40 30-40 1.1:1 WR-10 WG Details
Waveguide Directional Couplers OWD-4040H-15-BB OWD-4040H-15-BB 50 75 0.7 40 30-40 1.1:1 WR-15 WG Details
Waveguide Directional Couplers OWD-2040H-19-SB OWD-2040H-19-SB 40 60 0.7 20 35 1.1:1 WR-19 WG Details
Waveguide Directional Couplers OWD-2040H-22-SB OWD-2040H-22-SB 33 50 0.6 20 35 1.10:1 WR-22 WG Details
Waveguide Directional Couplers OWD-3040H-10-BB OWD-3040H-10-BB 75 110 1.0 30 30-40 1.1:1 WR-10 WG Details
Waveguide Directional Couplers OWD-3040H-12-BB OWD-3040H-12-BB 60 90 0.8 30 30-40 1.1:1 WR-12 WG Details
Waveguide Directional Couplers OWD-3040H-15-BB OWD-3040H-15-BB 50 75 0.7 30 30-40 1.1:1 WR-15 WG Details
Waveguide Directional Couplers OWD-3040H-19-SB OWD-3040H-19-SB 40 60 0.7 30 35 1.1:1 WR-19 WG Details
Waveguide Directional Couplers OWD-3040H-22-SB OWD-3040H-22-SB 33 50 0.6 30 35 1.10:1 WR-22 WG Details
Waveguide Directional Couplers OWD-4040H-10-BB OWD-4040H-10-BB 75 110 1.0 40 30-40 1.1:1 WR-10 WG Details
Waveguide Directional Couplers OWD-1040H-12-BB OWD-1040H-12-BB 60 90 0.8 10 30-40 1.1:1 WR-12 WG Details
Waveguide Directional Couplers OWD-1040H-15-BB OWD-1040H-15-BB 50 75 0.7 10 30-40 1.1:1 WR-15 WG Details
Waveguide Directional Couplers OWD-1040H-19-SB OWD-1040H-19-SB 40 60 0.7 10 35 1.1:1 WR-19 WG Details
Waveguide Directional Couplers OWD-1040H-22-SB OWD-1040H-22-SB 33 50 0.6 10 35 1.10:1 WR-08 WG Details
Waveguide Directional Couplers OWD-0340H-10-BB OWD-0340H-10-BB 75 110 1.0 3 3 1.1:1 WR-10 WG Details
Waveguide Directional Couplers OWD-2040H-10-BB OWD-2040H-10-BB 75 110 1.0 20 30-40 1.1:1 WR-10 WG Details
Waveguide Directional Couplers OWD-0340H-12-BB OWD-0340H-12-BB 60 90 0.8 3 30-40 1.1:1 WR-12 WG Details
Waveguide Directional Couplers OWD-2040H-10-DB OWD-2040H-10-DB 75 110 1.0 20 30-40 1.08:1 - 1.10:1, 1.12:1 - 1.15:1 WR-10 WG Details
Waveguide Directional Couplers OWD-0340H-15-BB OWD-0340H-15-BB 50 75 0.7 3 30-40 1.1:1 WR-15 WG Details
Waveguide Directional Couplers OWD-2040H-12-BB OWD-2040H-12-BB 60 90 0.8 20 30-40 1.1:1 WR-12 WG Details
Waveguide Directional Couplers OWD-0340H-19-SB OWD-0340H-19-SB 40 60 0.7 3 35 1.1:1 WR-19 WG Details
Waveguide Directional Couplers OWD-2040H-15-BB OWD-2040H-15-BB 50 75 0.7 20 30-40 1.1:1 WR-15 WG Details
Waveguide Directional Couplers OWD-0340H-22-SB OWD-0340H-22-SB 33 50 0.6 3 35 1.10:1 WR-22 WG Details
Waveguide Directional Couplers OWD-0640H-10-BB OWD-0640H-10-BB 75 110 1.0 6 30-40 1.1:1 WR-10 WG Details
Waveguide Directional Couplers OWD-0640H-12-BB OWD-0640H-12-BB 60 90 0.8 6 30-40 1.1:1 WR-12 WG Details
Waveguide Directional Couplers OWD-0640H-15-BB OWD-0640H-15-BB 50 75 0.7 6 40 1.1:1 WR-15 WG Details
Waveguide Directional Couplers OWD-0640H-19-SB OWD-0640H-19-SB 40 60 0.7 6 35 1.1:1 WR-19 WG Details
Waveguide Directional Couplers OWD-0640H-22-SB OWD-0640H-22-SB 33 50 0.6 6 35 1.10:1 WR-22 WG Details
Waveguide Directional Couplers OWD-1040H-10-BB OWD-1040H-10-BB 75 110 1.0 10 30-40 NA WR-10 WG Details
Waveguide Directional Couplers OWD-1040H-10-DB OWD-1040H-10-DB 75 110 1.0 10 30-40 1.08:1 - 1.10:1 WR-10 WG Details
Waveguide Directional Couplers OWD-5038531040H-15-SB OWD-5038531040H-15-SB 50.0 85 0.7 10 40 20 dB WR-15 WG Details
Waveguide Directional Couplers OWD-4040H-10-SB OWD-4040H-10-SB 75.0 110 1.0 40 40 1.1:1 WR-10 WG Details
Waveguide Directional Couplers OWD-4040H-12-SB OWD-4040H-12-SB 60.0 90 0.8 40 40 1.1:1 WR-12 WG Details
Waveguide Directional Couplers OWD-4040H-15-SB OWD-4040H-15-SB 50.0 75 0.7 40 40 1.1:1 WR-15 WG Details
Waveguide Directional Couplers OWD-4025H-06-SB OWD-4025H-06-SB 110.0 170 3.0 40 25 1.2:1 WR-06 WG Details
Waveguide Directional Couplers OWD-4030H-08-SB OWD-4030H-08-SB 90.0 140 2.5 40 30 1.2:1 WR-08 WG Details
Waveguide Directional Couplers OWD-2025H-06-SB OWD-2025H-06-SB 110.0 140 3.0 20 25 1.2:1 WR-06 WG Details
Waveguide Directional Couplers OWD-2030H-08-SB OWD-2030H-08-SB 90.0 140 2.5 20 30 1.2:1 WR-08 WG Details
Waveguide Directional Couplers OWD-2040H-10-SB OWD-2040H-10-SB 75.0 110 1.0 20 40 1.1:1 WR-10 WG Details
Waveguide Directional Couplers OWD-2040H-12-SB OWD-2040H-12-SB 60.0 90 0.8 20 40 1.1:1 WR-12 WG Details
Waveguide Directional Couplers OWD-2040H-15-SB OWD-2040H-15-SB 50.0 75 0.7 20 40 1.1:1 WR-15 WG Details
Waveguide Directional Couplers OWD-3025H-06-SB OWD-3025H-06-SB 110.0 170 3.0 30 25 1.2:1 WR-06 WG Details
Waveguide Directional Couplers OWD-3030H-08-SB OWD-3030H-08-SB 90.0 140 2.5 30 30 1.2:1 WR-08 WG Details
Waveguide Directional Couplers OWD-3040H-10-SB OWD-3040H-10-SB 75.0 110 1.0 30 40 1.1:1 WR-10 WG Details
Waveguide Directional Couplers OWD-3040H-12-SB OWD-3040H-12-SB 60.0 90 0.8 30 40 1.1:1 WR-12 WG Details
Waveguide Directional Couplers OWD-3040H-15-SB OWD-3040H-15-SB 50.0 75 0.7 30 40 1.1:1 WR-15 WG Details
Waveguide Directional Couplers OWD-0325H-06-SB OWD-0325H-06-SB 110.0 170 3.0 3 25 1.2:1 WR-06 WG Details
Waveguide Directional Couplers OWD-1040H-10-SB OWD-1040H-10-SB 75.0 110 1.0 10 40 1.1:1 WR-10 WG Details
Waveguide Directional Couplers OWD-0330H-08-SB OWD-0330H-08-SB 90.0 140 2.5 3 30 1.2:1 WR-08 WG Details
Waveguide Directional Couplers OWD-1040H-12-SB OWD-1040H-12-SB 60.0 90 0.8 10 40 1.1:1 WR-12 WG Details
Waveguide Directional Couplers OWD-0340H-10-SB OWD-0340H-10-SB 75.0 110 1.0 3 40 1.1:1 WR-10 WG Details
Waveguide Directional Couplers OWD-1040H-15-SB OWD-1040H-15-SB 50.0 75 0.7 10 40 1.1:1 WR-15 WG Details
Waveguide Directional Couplers OWD-0340H-12-SB OWD-0340H-12-SB 60.0 90 0.8 3 40 1.1:1 WR-12 WG Details
Waveguide Directional Couplers OWD-1040H-28-SB OWD-1040H-28-SB 26.5 40 0.5 10 40 1.1:1 WR-28 WG Details
Waveguide Directional Couplers OWD-0340H-15-SB OWD-0340H-15-SB 50.0 75 0.7 3 40 1.1:1 WR-15 WG Details
Waveguide Directional Couplers OWD-0340H-28-SB OWD-0340H-28-SB 26.5 40 0.5 3 40 1.1:1 WR-28 WG Details
Waveguide Directional Couplers OWD-0625H-06-SB OWD-0625H-06-SB 110.0 170 3.0 6 25 1.2:1 WR-06 WG Details
Waveguide Directional Couplers OWD-0630H-08-SB OWD-0630H-08-SB 90.0 140 2.5 6 30 1.2:1 WR-08 WG Details
Waveguide Directional Couplers OWD-0640H-10-SB OWD-0640H-10-SB 75.0 110 1.0 6 40 1.1:1 WR-10 WG Details
Waveguide Directional Couplers OWD-0640H-12-SB OWD-0640H-12-SB 60.0 90 0.8 6 40 1.1:1 WR-12 WG Details
Waveguide Directional Couplers OWD-0640H-15-SB OWD-0640H-15-SB 50.0 75 0.7 6 40 1.1:1 WR-15 WG Details
Waveguide Directional Couplers OWD-0640H-28-SB OWD-0640H-28-SB 26.5 40 0.5 6 40 1.1:1 WR-28 WG Details
Waveguide Directional Couplers OWD-1025H-06-SB OWD-1025H-06-SB 110.0 170 3.0 10 25 1.2:1 WR-06 WG Details
Waveguide Directional Couplers OWD-1030E-12-SW OWD-1030E-12-SW 60.0 90 1.0 10 30 1.1:1 WR-12 WG Details
Waveguide Directional Couplers OWD-1030H-08-SB OWD-1030H-08-SB 90.0 140 2.5 10 30 1.2:1 WR-08 WG Details
Waveguide Directional Couplers OWD-1030H-12-SW OWD-1030H-12-SW 60.0 90 1.0 10 30 1.1:1 WR-12 WG Details
Product product-code min-freq-ghz max-freq-ghz insertion-length waveguide-size flange-1 flange-2 Action
WAVEGUIDE FLANGE ADAPTERS OWR-6090-S OWR-6090-S 60.0 90.0 1 WR-12 Waveguide UG-387/U Flange UG-383/U-M Flange Details
WAVEGUIDE FLANGE ADAPTERS OWR-110170-S OWR-110170-S 110.0 170.0 1 WR-06 Waveguide UG-387/U-M Flange UG-383/U-M Flange Details
WAVEGUIDE FLANGE ADAPTERS OWR-5075-S OWR-5075-S 50.0 75.0 1 WR-15 Waveguide UG-385/U Flange UG-383/U-M Flange Details
WAVEGUIDE FLANGE ADAPTERS OWR-75110-S OWR-75110-S 75.0 110.0 1 WR-10 Waveguide UG-387/U-M Flange UG-383/U-M Flange Details
WAVEGUIDE FLANGE ADAPTERS OWR-3350-S OWR-3350-S 33.0 50.0 1 WR-22 Waveguide UG-383/U Flange UG-599/U-M Flange Details
WAVEGUIDE FLANGE ADAPTERS OWR-90140-S OWR-90140-S 90.0 140.0 1 WR-08 Waveguide UG-387/U-M Flange UG-383/U-M Flange Details
WAVEGUIDE FLANGE ADAPTERS OWR-4060-S OWR-4060-S 40.0 60.0 1 WR-19 Waveguide UG-383/U-M Flange UG-599/U-M Flange Details
WAVEGUIDE FLANGE ADAPTERS OWR-1827-S OWR-1827-S 18.0 26.5 1 WR-42 Waveguide UG-383/U-M Flange UG-595/U Flange Details
WAVEGUIDE FLANGE ADAPTERS OWR-2740-S OWR-2740-S 26.5 40.0 1 WR-28 Waveguide UG-383/U-M Flange UG-599/U Flange Details
Product product-code min-freq-ghz max-freq-ghz insertion-loss-db port-isolation-db way Action
Waveguide Power Divider OWP-4-710860-E OWP-4-710860-E 71.0 86.0 1.0 20.0 4 Details
Waveguide Power Divider OWP-8-290310-E OWP-8-290310-E 28.5 30.0 0.5 25.0 8 Details
Waveguide Power Divider OWP-16-290350-E OWP-16-290350-E 29.0 35.0 1.2 20.0 16 Details
Waveguide Power Divider OWP-8-500660-E OWP-8-500660-E 55.0 66.0 1.7 20.0 8 Details
Waveguide Power Divider OWP-4-9001050-E OWP-4-9001050-E 90.0 105.0 1.0 20.0 4 Details
Waveguide Power Divider OWP-4-920960-E OWP-4-920960-E 92.0 96.0 1.0 20.0 4 Details
Waveguide Power Divider OWP-4-710860-E1 OWP-4-710860-E1 71.0 86.0 0.8 25.0 4 Details
Waveguide Power Divider OWP-4-460470-E OWP-4-460470-E 46.0 47.0 2.0 20.0 4 Details
Waveguide Power Divider OWP-4-550670-E OWP-4-550670-E 55.0 67.0 1.0 20.0 4 Details
Waveguide Power Divider OWP-4-590610-E OWP-4-590610-E 59.0 61.0 1.0 25.0 4 Details
Waveguide Power Divider OWP-4-400500-E OWP-4-400500-E 40.0 50.0 0.5 20.0 4 Details
Waveguide Power Divider OWP-2-270400-E OWP-2-270400-E 27.0 40.0 0.4 20.0 2 Details
Waveguide Power Divider OWP-4-300400-E OWP-4-300400-E 30.0 40.0 0.5 20.0 4 Details
Waveguide Power Divider OWP-4-290310-E OWP-4-290310-E 29.0 31.0 0.5 25.0 4 Details
Waveguide Power Divider OWP-4-290320-E OWP-4-290320-E 29.0 32.0 0.6 20.0 4 Details
Waveguide Power Divider OWP-2-710860-E OWP-2-710860-E 71.0 86.0 0.8 18.0 2 Details
Waveguide Power Divider OWP-4-270350-E OWP-4-270350-E 26.5 35.0 0.5 25.0 4 Details
Waveguide Power Divider OWP-2-600900-E1 OWP-2-600900-E1 60.0 90.0 0.8 18.0 2 Details
Waveguide Power Divider OWP-2-7501100-E2 OWP-2-7501100-E2 75.0 110.0 0.5 20.0 2 Details
Waveguide Power Divider OWP-2-500700-E OWP-2-500700-E 50.0 70.0 0.5 20.0 2 Details
Waveguide Power Divider OWP-2-600900-E OWP-2-600900-E 60.0 90.0 0.4 20.0 2 Details
Waveguide Power Divider OWP-2-430470-E OWP-2-430470-E 43.0 47.0 0.3 20.0 2 Details
Waveguide Power Divider OWP-2-500750-E OWP-2-500750-E 50.0 75.0 0.5 20.0 2 Details
Waveguide Power Divider OWP-2-400500-E OWP-2-400500-E 40.0 50.0 0.3 20.0 2 Details
Waveguide Power Divider OWP-4-620860-E2 OWP-4-620860-E2 62.0 86.0 0.8 20.0 4 Details
Waveguide Power Divider OWP-2-300400-E OWP-2-300400-E 30.0 40.0 0.4 20.0 2 Details
Waveguide Power Divider OWP-4-500750-E OWP-4-500750-E 50.0 75.0 1.0 20.0 4 Details
Product product-code min-freq-ghz max-freq-ghz insertion-length mils waveguide-size Action
Waveguide Shims and Spacers OWI-3355-138 OWI-3355-138 33 55 0.138" (L) 138 WR-22 Waveguide Details
Waveguide Shims and Spacers OWI-2233-69 OWI-2233-69 22 33 0.069" (L) 69 WR-34 Waveguide Details
Waveguide Shims and Spacers OWI-110170-42 OWI-110170-42 110 170 0.042" (L) 42 WR-06 Waveguide Details
Waveguide Shims and Spacers OWI-5075-31 OWI-5075-31 50 75 0.031" (L) 31 WR-15 Waveguide Details
Waveguide Shims and Spacers OWI-140220-32 OWI-140220-32 140 220 0.032" (L) 32 WR-05 Waveguide Details
Waveguide Shims and Spacers OWI-75110-21 OWI-75110-21 75 110 0.021" (L) 21 WR-10 Waveguide Details
Waveguide Shims and Spacers OWI-110170-28 OWI-110170-28 110 170 0.028" (L) 28 WR-06 Waveguide Details
Waveguide Shims and Spacers OWI-90140-33 OWI-90140-33 90 140 0.033" (L) 33 WR-08 Waveguide Details
Waveguide Shims and Spacers OWI-75110-62 OWI-75110-62 75 110 0.062" (L) 62 WR-10 Waveguide Details
Waveguide Shims and Spacers OWI-75110-41 OWI-75110-41 75 110 0.041" (L) 41 WR-10 Waveguide Details
Waveguide Shims and Spacers OWI-90140-17 OWI-90140-17 90 140 0.017" (L) 17 WR-08 Waveguide Details
Waveguide Shims and Spacers OWI-6090-52 OWI-6090-52 60 90 0.052" (L) 52 WR-12 Waveguide Details
Waveguide Shims and Spacers OWI-140220-21 OWI-140220-21 140 220 0.021" (L) 21 WR-05 Waveguide Details
Waveguide Shims and Spacers OWI-6090-26 OWI-6090-26 60 90 0.026" (L) 26 WR-12 Waveguide Details
Waveguide Shims and Spacers OWI-140220-11 OWI-140220-11 140 220 0.011" (L) 11 WR-05 Waveguide Details
Waveguide Shims and Spacers OWI-6090-77 OWI-6090-77 60 90 0.077" (L) 77 WR-12 Waveguide Details
Waveguide Shims and Spacers OWI-3350-46 OWI-3350-46 33 50 0.046" (L) 46 WR-22 Waveguide Details
Waveguide Shims and Spacers OWI-4060-114 OWI-4060-114 40 60 0.114" (L) 114 WR-19 Waveguide Details
Waveguide Shims and Spacers OWI-4060-38 OWI-4060-38 40 60 0.038" (L) 38 WR-19 Waveguide Details
Waveguide Shims and Spacers OWI-5075-92 OWI-5075-92 50 75 0.092" (L) 92 WR-15 Waveguide Details
Waveguide Shims and Spacers OWI-3350-92 OWI-3350-92 33 50 0.092" (L) 92 WR-22 Waveguide Details
Waveguide Shims and Spacers OWI-90140-50 OWI-90140-50 90 140 0.050" (L) 50 WR-08 Waveguide Details
Waveguide Shims and Spacers OWI-110170-14 OWI-110170-14 110 170 0.014”(L) 14 WR-06 Waveguide Details
Waveguide Shims and Spacers OWI-75110-25 OWI-75110-25 75 110 0.025”(L) 25 WR-10 Waveguide Details
Waveguide Shims and Spacers OWI-2233-138 OWI-2233-138 22 33 0.138" (L) 138 WR-34 Waveguide Details
Waveguide Shims and Spacers OWI-2233-208 OWI-2233-208 22 33 0.208" (L) 208 WR-34 Waveguide Details
Waveguide Shims and Spacers OWI-5040-61 OWI-5040-61 50 40 0.061”(L) 61 WR-15 Waveguide Details
Waveguide Shims and Spacers OWI-1827-171 OWI-1827-171 18 26.5 0.171”(L) 171 WR-42 Waveguide Details
Waveguide Shims and Spacers OWI-3350-96 OWI-3350-96 33 50 0.096”(L) 96 WR-22 Waveguide Details
Waveguide Shims and Spacers OWI-1827-257 OWI-1827-257 18 26.5 0.257”(L) 257 WR-06 Waveguide Details
Waveguide Shims and Spacers OWI-1827-84 OWI-1827-84 18 26.5 0.084" (L) 84 WR-42 Waveguide Details
Waveguide Shims and Spacers OWI-75110-40 OWI-75110-40 75 110 0.040”(L) 40 WR-10 Waveguide Details
Waveguide Shims and Spacers OWI-4060-76 OWI-4060-76 40 60 0.076”(L) 76 WR-19 Waveguide Details
Waveguide Shims and Spacers OWI-4060-75 OWI-4060-75 40 60 0.075”(L) 75 WR-19 Waveguide Details
Waveguide Shims and Spacers OWI-6090-51 OWI-6090-51 60 90 0.051”(L) 51 WR-22 Waveguide Details
Waveguide Shims and Spacers OWI-3350-50 OWI-3350-50 33 50 0.096”(L) 50 WR-22 Waveguide Details
Waveguide Shims and Spacers OWI-4060-112 OWI-4060-112 40 60 0.112” (L) 112 WR-19 Waveguide Details
Waveguide Shims and Spacers OWI-75110-20 OWI-75110-20 75 110 0.020”(L) 20 WR-10 Waveguide Details
Waveguide Shims and Spacers OWI-1827-252 OWI-1827-252 18 26.5 0.252" (L) 252 WR-42 Waveguide Details
Waveguide Shims and Spacers OWI-1827-168 OWI-1827-168 18 26.5 0.168" (L) 168 WR-42 Waveguide Details
Waveguide Shims and Spacers OWI-2233-207 OWI-2233-207 22 33 0.207”(L) 207 WR-34 Waveguide Details
Product product-code min-freq-ghz max-freq-ghz waveguide-size insertion-length Action
Waveguide Straight Section OWG-3350-1-A OWG-3350-1-A 33.0 50.0 WR-22 Waveguide 1" Details
Waveguide Straight Section OWG-3350-2 OWG-3350-2 33.0 50.0 WR-22 Waveguide 2" Details
Waveguide Straight Section OWG-2740-1 OWG-2740-1 26.5 40.0 WR-28 Waveguide 1" Details
Waveguide Straight Section OWG-2740-2 OWG-2740-2 26.5 40.0 WR-28 Waveguide 2" Details
Waveguide Straight Section OWG-4060-2 OWG-4060-2 40.0 60.0 WR-19 Waveguide 2" Details
Waveguide Straight Section OWG-3350-1-B OWG-3350-1-B 33.0 50.0 WR-22 Waveguide 1" Details
Waveguide Straight Section OWG-1928-2 OWG-1928-2 18.5 26.5 WR-42 Waveguide 2" Details
Waveguide Straight Section OWG-2233-2 OWG-2233-2 22.0 33.0 WR-34 Waveguide 2" Details
Waveguide Straight Section OWG-1928-1 OWG-1928-1 18.5 26.5 WR-42 Waveguide 1" Details
Waveguide Straight Section OWG-2233-1 OWG-2233-1 22.0 33.0 WR-34 Waveguide 1" Details
Waveguide Straight Section OWG-3350-15 OWG-3350-15 33.0 50.0 WR-22 Waveguide 1.5" Details
Waveguide Straight Section OWG-220325-1 OWG-220325-1 220.0 325.0 WR-03 Waveguide 1" Details
Waveguide Straight Section OWG-5075-2 OWG-5075-2 50.0 75.0 WR-15 Waveguide 2" Details
Waveguide Straight Section OWG-90140-2 OWG-90140-2 90.0 140.0 WR-08 Waveguide 2" Details
Waveguide Straight Section OWG-110170-2 OWG-110170-2 110.0 170.0 WR-06 Waveguide 2" Details
Waveguide Straight Section OWG-6090-15 OWG-6090-15 60.0 90.0 WR-12 Waveguide 1.5" Details
Waveguide Straight Section OWG-6090-4 OWG-6090-4 60.0 90.0 WR-12 Waveguide 4" Details
Waveguide Straight Section OWG-75110-1 OWG-75110-1 75.0 110.0 WR-10 Waveguide 1" Details
Waveguide Straight Section OWG-5075-1 OWG-5075-1 50.0 75.0 WR-15 Waveguide 1" Details
Waveguide Straight Section OWG-6090-2 OWG-6090-2 60.0 90.0 WR-12 Waveguide 2" Details
Waveguide Straight Section OWG-75110-2 OWG-75110-2 75.0 110.0 WR-10 Waveguide 2" Details
Waveguide Straight Section OWG-5075-15 OWG-5075-15 50.0 75.0 WR-15 Waveguide 1.5" Details
Waveguide Straight Section OWG-6090-125 OWG-6090-125 60.0 90.0 WR-12 Waveguide 1.25" Details
Waveguide Straight Section OWG-4060-1 OWG-4060-1 40.0 60.0 WR-19 Waveguide 1" Details
Waveguide Straight Section OWG-6090-05 OWG-6090-05 60.0 90.0 WR-12 Waveguide 0.5" Details
Waveguide Straight Section OWG-90140-1 OWG-90140-1 90.0 140.0 WR-08 Waveguide 1" Details
Waveguide Straight Section OWG-140220-2 OWG-140220-2 140.0 220.0 WR-05 Waveguide 2" Details
Waveguide Straight Section OWG-6090-1 OWG-6090-1 60.0 90.0 WR-12 Waveguide 1" Details
Waveguide Straight Section OWG-140220-1 OWG-140220-1 140.0 220.0 WR-05 Waveguide 1" Details
Waveguide Straight Section OWG-110170-1 OWG-110170-1 110.0 170.0 WR-06 Waveguide 1" Details
Product product-code waveguide-size-1 waveguide-size-2 transition-type insertion-length Action
Waveguide Taper and Mode Transitions OWT-5122 OWT-5122 WR-51 Waveguide WR-22 Waveguide Taper 3.0 Details
Waveguide Taper and Mode Transitions OWT-90797 OWT-90797 WR-90 Waveguide 0.797" Diameter Circular Waveguide Mode 3.5 Details
Waveguide Taper and Mode Transitions OWT-90900 OWT-90900 WR-90 Waveguide 0.900" Diameter Circular Waveguide Mode 3.5 Details
Waveguide Taper and Mode Transitions OWT-5115 OWT-5115 WR-51 Waveguide WR-15 Waveguide Taper 3.0 Details
Waveguide Taper and Mode Transitions OWT-90938 OWT-90938 WR-90 Waveguide 0.938" Diameter Circular Waveguide Mode 3.5 Details
Waveguide Taper and Mode Transitions OWT-340328 OWT-340328 0.340" Square Waveguide 0.328" Dia Circular Waveguide Mode 0.5 Details
Waveguide Taper and Mode Transitions OWT-340315-599 OWT-340315-599 0.340" Square Waveguide 0.315" Dia Circular Waveguide Mode 0.7 Details
Waveguide Taper and Mode Transitions OWT-42436 OWT-42436 WR-42 Waveguide 0.436" Diameter Circular Waveguide Mode 2.0 Details
Waveguide Taper and Mode Transitions OWT-42470 OWT-42470 WR-42 Waveguide 0.470" Diameter Circular Waveguide Mode 2.0 Details
Waveguide Taper and Mode Transitions OWT-42396 OWT-42396 WR-42 Waveguide 0.396" Diameter Circular Waveguide Mode 2.0 Details
Waveguide Taper and Mode Transitions OWT-42368 OWT-42368 WR-42 Waveguide 0.368" Diameter Circular Waveguide Mode 2.0 Details
Waveguide Taper and Mode Transitions OWT-4228 OWT-4228 WR-42 Waveguide WR-28 Waveguide Taper 2.5 Details
Waveguide Taper and Mode Transitions OWT-4234 OWT-4234 WR-42 Waveguide WR-34 Rectangular Waveguide Taper 2.0 Details
Waveguide Taper and Mode Transitions OWT-34328 OWT-34328 WR-34 Waveguide 0.328" Diameter Circular Waveguide Mode 2.0 Details
Waveguide Taper and Mode Transitions OWT-3428 OWT-3428 WR-34 Waveguide WR-28 Waveguide Taper 2.0 Details
Waveguide Taper and Mode Transitions OWT-280315 OWT-280315 0.280" Square Waveguide 0.315" Dia Circular Waveguide Mode 0.7 Details
Waveguide Taper and Mode Transitions OWT-1910 OWT-1910 WR-19 Waveguide WR-10 Waveguide Taper 1.5 Details
Waveguide Taper and Mode Transitions OWT-280358 OWT-280358 0.280" Square Waveguide 0.358" Dia Circular Waveguide Mode 0.7 Details
Waveguide Taper and Mode Transitions OWT-2210 OWT-2210 WR-22 Waveguide WR-10 Waveguide Taper 1.5 Details
Waveguide Taper and Mode Transitions OWT-19188 OWT-19188 WR-19 Waveguide 0.188" Diameter Circular Waveguide Mode 1.5 Details
Waveguide Taper and Mode Transitions OWT-2810 OWT-2810 WR-28 Waveguide WR-10 Waveguide Taper 2.0 Details
Waveguide Taper and Mode Transitions OWT-28315 OWT-28315 WR-28 Waveguide 0.315" Diameter Circular Waveguide Mode 1.5 Details
Waveguide Taper and Mode Transitions OWT-2819 OWT-2819 WR-28 Waveguide WR-19 Waveguide Taper 2.0 Details
Waveguide Taper and Mode Transitions OWT-2822 OWT-2822 WR-28 Waveguide WR-22 Waveguide Taper 2.0 Details
Waveguide Taper and Mode Transitions OWT-2822-599 OWT-2822-599 WR-28 Waveguide WR-22 Waveguide Taper 2.0 Details
Waveguide Taper and Mode Transitions OWT-280328 OWT-280328 0.280" Square Waveguide 0.328" Dia Circular Waveguide Mode 0.7 Details
Waveguide Taper and Mode Transitions OWT-2215 OWT-2215 WR-22 Waveguide WR-15 Waveguide Taper 1.5 Details
Waveguide Taper and Mode Transitions OWT-280250 OWT-280250 0.280" Square Waveguide 0.250" Dia Circular Waveguide Mode 0.7 Details
Waveguide Taper and Mode Transitions OWT-1915 OWT-1915 WR-19 Waveguide WR-15 Waveguide Taper 1.5 Details
Waveguide Taper and Mode Transitions OWT-224219 OWT-224219 0.224" Square Waveguide 0.219" Circular Waveguide Mode 0.8 Details
Waveguide Taper and Mode Transitions OWT-22219 OWT-22219 WR-22 Waveguide 0.219" Diameter Circular Waveguide Mode 1.5 Details
Waveguide Taper and Mode Transitions OWT-28328-381 OWT-28328-381 WR-28 Waveguide 0.328" Diameter Circular Waveguide Mode 2.0 Details
Waveguide Taper and Mode Transitions OWT-2212 OWT-2212 WR-22 Waveguide WR-12 Waveguide Taper 1.5 Details
Waveguide Taper and Mode Transitions OWT-340315 OWT-340315 0.340" Square Waveguide 0.315" Dia Circular Waveguide Mode 0.5 Details
Waveguide Taper and Mode Transitions OWT-2219 OWT-2219 WR-22 Waveguide WR-19 Waveguide Taper 1.5 Details
Waveguide Taper and Mode Transitions OWT-15141-2 OWT-15141-2 WR-15 Waveguide 0.141" x 0.141" Square WG Mode 1.0 Details
Waveguide Taper and Mode Transitions OWT-1512-1 OWT-1512-1 WR-15 Waveguide WR-12 Waveguide Taper 1.0 Details
Waveguide Taper and Mode Transitions OWT-1512-2 OWT-1512-2 WR-15 Waveguide WR-12 Waveguide Taper 1.0 Details
Waveguide Taper and Mode Transitions OWT-15165 OWT-15165 WR-15 Waveguide 0.165" Diameter Circular Waveguide Mode 1.0 Details
Waveguide Taper and Mode Transitions OWT-15141-1 OWT-15141-1 WR-15 Waveguide 0.141" Diameter Circular Waveguide Mode 1.0 Details
Waveguide Taper and Mode Transitions OWT-1510 OWT-1510 WR-15 Waveguide WR-10 Waveguide Taper 1.0 Details
Waveguide Taper and Mode Transitions OWT-1210-2 OWT-1210-2 WR-12 Waveguide WR-10 Waveguide Taper 1.0 Details
Waveguide Taper and Mode Transitions OWT-1208 OWT-1208 WR-12 Waveguide WR-08 Waveguide Taper 1.0 Details
Waveguide Taper and Mode Transitions OWT-1210-1 OWT-1210-1 WR-12 Waveguide WR-10 Waveguide Taper 1.0 Details
Waveguide Taper and Mode Transitions OWT-12125 OWT-12125 WR-12 Waveguide 0.125" Diameter Circular Waveguide Mode 1.0 Details
Waveguide Taper and Mode Transitions OWT-12110 OWT-12110 WR-12 Waveguide 0.110" Diameter Circular Waveguide Mode 1.0 Details
Waveguide Taper and Mode Transitions OWT-148141 OWT-148141 0.148" x 0.148" Square Waveguide 0.141" Dia Circular Waveguide Mode 1.0 Details
Waveguide Taper and Mode Transitions OWT-122165 OWT-122165 0.122" x 0.122" Square Waveguide 0.165" Dia Circular Waveguide Mode 1.0 Details
Waveguide Taper and Mode Transitions OWT-122125 OWT-122125 0.122" x 0.122" Square Waveguide 0.125" Dia Circular Waveguide Mode 1.0 Details
Waveguide Taper and Mode Transitions OWT-12136 OWT-12136 WR-12 Waveguide 0.136" Diameter Circular Waveguide Mode 1.0 Details
Waveguide Taper and Mode Transitions OWT-100094 OWT-100094 0.100" x 0.100" Square Waveguide 0.094" Dia Circular Waveguide Mode 1.0 Details
Waveguide Taper and Mode Transitions OWT-10094 OWT-10094 WR-10 Waveguide 0.094" Diameter Circular Waveguide Mode 1.0 Details
Waveguide Taper and Mode Transitions OWT-06067 OWT-06067 WR-06 Waveguide 0.067" Diameter Circular Waveguide Mode 1.0 Details
Waveguide Taper and Mode Transitions OWT-10110 OWT-10110 WR-10 Waveguide 0.110" Diameter Circular Waveguide Mode 1.0 Details
Waveguide Taper and Mode Transitions OWT-0604 OWT-0604 WR-06 Waveguide WR-04 Waveguide Taper 1.0 Details
Waveguide Taper and Mode Transitions OWT-0504 OWT-0504 WR-05 Waveguide WR-04 Waveguide Taper 1.0 Details
Waveguide Taper and Mode Transitions OWT-1008 OWT-1008 WR-10 Waveguide WR-08 Waveguide Taper 1.0 Details
Waveguide Taper and Mode Transitions OWT-06075 OWT-06075 WR-06 Waveguide 0.075" Diameter Circular Waveguide Mode 1.0 Details
Waveguide Taper and Mode Transitions OWT-06059 OWT-06059 WR-06 Waveguide 0.059" Diameter Circular Waveguide Mode 1.0 Details
Waveguide Taper and Mode Transitions OWT-1206 OWT-1206 WR-12 Waveguide WR-06 Waveguide Taper 1.0 Details
Waveguide Taper and Mode Transitions OWT-05059 OWT-05059 WR-05 Waveguide 0.059" Diameter Circular Waveguide Mode 1.0 Details
Waveguide Taper and Mode Transitions OWT-1006 OWT-1006 WR-10 Waveguide WR-06 Waveguide Taper 1.0 Details
Waveguide Taper and Mode Transitions OWT-0805 OWT-0805 WR-08 Waveguide WR-05 Waveguide Taper 1.0 Details
Waveguide Taper and Mode Transitions OWT-0806-1 OWT-0806-1 WR-08 Waveguide WR-06 Waveguide Taper 1.0 Details
Waveguide Taper and Mode Transitions OWT-0806-2 OWT-0806-2 WR-08 Waveguide WR-06 Waveguide Taper 1.0 Details
Waveguide Taper and Mode Transitions OWT-08075 OWT-08075 WR-08 Waveguide 0.075" Diameter Circular Waveguide Mode 1.0 Details
Waveguide Taper and Mode Transitions OWT-0605 OWT-0605 WR-06 Waveguide WR-05 Waveguide Taper 1.0 Details
Waveguide Taper and Mode Transitions OWT-08082 OWT-08082 WR-08 Waveguide 0.082" Diameter Circular Waveguide Mode 1.0 Details
Waveguide Taper and Mode Transitions OWT-1004 OWT-1004 WR-10 Waveguide WR-04 Waveguide Taper 1.0 Details
Waveguide Taper and Mode Transitions OWT-1005 OWT-1005 WR-10 Waveguide WR-05 Waveguide Taper 1.0 Details
Product product-code min-freq-ghz max-freq-ghz vswr power-handling-w-cw waveguide flange return-loss-db Action
Waveguide TerminationsOWL-0627-S OWL-0627-S 110.0 170.0 1.10 : 1 0.5-1.0 WR-06 UG-387/U-M NA Details
Waveguide TerminationsOWL-0637-S OWL-0637-S 110.0 170.0 1.10 : 1 5.0-6.0 WR-06 UG-387/U-M NA Details
Waveguide TerminationsOWL-0827-S OWL-0827-S 90.0 140.0 1.10 : 1 0.5-1.0 WR-08 UG-387/U-M NA Details
Waveguide TerminationsOWL-0837-S OWL-0837-S 90.0 140.0 1.10 : 1 5.0-6.0 WR-08 UG-387/U-M NA Details
Waveguide TerminationsOWL-1027-S OWL-1027-S 75.0 110.0 1.10 : 1 0.5-2.0 WR-10 UG-387/U-M NA Details
Waveguide TerminationsOWL-1037-S OWL-1037-S 75.0 110.0 1.06 : 1 5.0-6.0 WR-10 UG-387/U-M NA Details
Waveguide TerminationsOWL-1227-S OWL-1227-S 60.0 90.0 1.05 : 1 0.5-2.0 WR-12 UG-387/U NA Details
Waveguide TerminationsOWL-1237-S OWL-1237-S 60.0 90.0 1.06 : 1 5.0-6.0 WR-12 UG-387/U NA Details
Waveguide TerminationsOWL-1527-S OWL-1527-S 50.0 75.0 1.05 : 1 0.5-2.0 WR-15 UG-385/U NA Details
Waveguide TerminationsOWL-1537-S OWL-1537-S 50.0 75.0 1.06 : 1 5.0-6.0 WR-15 UG-385/U NA Details
Waveguide TerminationsOWL-1930-S OWL-1930-S 40.0 60.0 1.05 : 1 1.0-2.0 WR-19 UG-383/U NA Details
Waveguide TerminationsOWL-2230-S OWL-2230-S 33.0 50.0 1.04 : 1 1.0-2.0 WR-22 UG-383/U NA Details
Waveguide TerminationsOWL-2832-S OWL-2832-S 26.5 40.0 1.04 : 1 1.5 -2.0 WR-28 UG-599/U NA Details
Waveguide TerminationsOWL-2846-S OWL-2846-S 26.5 40.0 1.25 : 1 28.0-30.0 WR-28 UG-599/U NA Details
Waveguide TerminationsOWL-2860-S OWL-2860-S 26.5 40.0 1.25 : 1 900-1000 WR-28 UG-599/U NA Details
Product product-code min-freq-ghz max-freq-ghz insertion-loss-db return-loss-db power-handling-w waveguide-size coaxile-mm Action
Waveguide to Coax Panel Moumt Adapters OWC-28E-292-M-B OWC-28E-292-M-B 26.5 40 0.3 20 50 WR-28 with UG599/U Flange with Threaded Holes 2.92 mm (K) Male Details
Waveguide to Coax Panel Moumt Adapters OWC-28E-292-F-C OWC-28E-292-F-C 26.5 40 0.3 20 50 WR-28 with Non-Standard UBR320 Flange 2.92 mm (K) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-28E-292-M-C OWC-28E-292-M-C 26.5 40 0.3 20 50 WR-28 with UG599/U Flange with Threaded Holes 2.92 mm (K) Male Details
Waveguide to Coax Panel Moumt Adapters OWC-28E-185-F OWC-28E-185-F 26.5 40 0.3 20 40 WR-28 with UG-599/U Flange 1.85 mm (V) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-28E-292-F-B OWC-28E-292-F-B 26.5 40 0.3 20 50 WR-28 with UG599/U Flange with Threaded Holes 2.92 mm (K) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-28R-292-M-A OWC-28R-292-M-A 26.5 40 0.3 20 50 WR-28 with UG599/U Flange 2.92 mm (K) Male Details
Waveguide to Coax Panel Moumt Adapters OWC-28E-185-M OWC-28E-185-M 26.5 40 0.3 20 40 WR-28 with UG-599/U Flange 1.85 mm (V) Male Details
Waveguide to Coax Panel Moumt Adapters OWC-28E-292-F-D OWC-28E-292-F-D 26.5 40 0.3 20 50 WR-28 with UG-599/U Flange with O-Ring 2.92 mm (K) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-28R-292-F-A OWC-28R-292-F-A 26.5 40 0.3 20 50 WR-28 with UG599/U Flange 2.92 mm (K) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-15E-185-M-C OWC-15E-185-M-C 50 70 0.4 20 40 WR-15 with UG-385/U Flange 1.85 mm (V) Male Details
Waveguide to Coax Panel Moumt Adapters OWC-22E-292-F OWC-22E-292-F 33 40 0.3 1.3:1 50 WR-22 with UG383/U Flange 2.92 mm (K) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-15E-185-F-A OWC-15E-185-F-A 50 70 0.4 16 40 WR-15 with UG385/U Anti-Cocking Flange 1.85 mm (V) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-22E-292-M OWC-22E-292-M 33 40 0.3 1.3:1 50 WR-22 with UG383/U Flange 2.92 mm (K) Male Details
Waveguide to Coax Panel Moumt Adapters OWC-22E-185-M OWC-22E-185-M 33 50 0.3 18 40 WR-22 with UG383/U Flange 1.85 mm (V) Male Details
Waveguide to Coax Panel Moumt Adapters OWC-22R-292-F-B OWC-22R-292-F-B 33 43 0.3 18 50 WR-22 with UG599/U-M Square Flange 2.92 mm (K) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-15R-185-F-A OWC-15R-185-F-A 50 70 0.5 16 40 WR-15 with UG385/U Flange 1.85 mm (V) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-15E-185-F-C OWC-15E-185-F-C 50 70 0.4 16 40 WR-15 with UG-385/U Flange 1.85 mm (V) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-15R-185-M-A OWC-15R-185-M-A 50 70 0.5 16 40 WR-15 with UG385/U Flange 1.85 mm (V) Male Details
Waveguide to Coax Panel Moumt Adapters OWC-28E-292-F-A OWC-28E-292-F-A 26.5 40 0.3 20 50 WR-28 with UG599/U Flange 2.92 mm (K) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-15R-185-F-B OWC-15R-185-F-B 50 70 0.4 16 30 WR-15 with UG-385/U Flange with O-Ring 1.85 mm (V) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-15E-185-F-D OWC-15E-185-F-D 50 70 0.4 16 40 WR-15 with UG-385/U Flange with O-Ring 1.85 mm (V) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-15R-185-M-B OWC-15R-185-M-B 50 70 0.4 16 30 WR-15 with UG-385/U Flange with O-Ring 1.85 mm (V) Male Details
Waveguide to Coax Panel Moumt Adapters OWC-19E-185-M OWC-19E-185-M 40 60 0.4 18 40 WR-19 with UG383/U-M Flange 1.85 mm (V) Male Details
Waveguide to Coax Panel Moumt Adapters OWC-22E-185-F OWC-22E-185-F 33 50 0.3 18 40 WR-22 with UG383/U Flange 1.85 mm (V) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-15E-185-F-B OWC-15E-185-F-B 50 70 0.4 16 40 WR-15 with UG385/U Anti-Cocking Flange 1.85 mm (V) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-19E-185-F OWC-19E-185-F 40 60 0.4 18 40 WR-19 with UG383/U-M Flange 1.85 mm (V) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-15E-185-M-B OWC-15E-185-M-B 50 70 0.4 16 40 WR-15 with UG385/U Anti-Cocking Flange 1.85 mm (V) Male Details
Waveguide to Coax Panel Moumt Adapters OWC-15E-185-M-A OWC-15E-185-M-A 50 70 0.4 16 40 WR-15 with UG385/U Flange 1.85 mm (V) Male Details
Waveguide to Coax Panel Moumt Adapters OWC-22R-292-M-B OWC-22R-292-M-B 33 43 0.3 18 50 WR-22 with UG599/U-M Square Flange 2.92 mm (K) Male Details
Waveguide to Coax Panel Moumt Adapters OWC-34E-240-F OWC-34E-240-F 22 33 0.3 20 50 WR-34 Waveguide with UG-1530/U Flange 2.4 mm Female Details
Waveguide to Coax Panel Moumt Adapters OWC-34R-240-F OWC-34R-240-F 22 33 0.3 20 50 WR-34 Waveguide with UG-1530/U Flange 2.4 mm Female Details
Waveguide to Coax Panel Moumt Adapters OWC-34E-240-M OWC-34E-240-M 22 33 0.3 20 50 WR-34 Waveguide with UG-1530/U Flange 2.4 mm Male Details
Waveguide to Coax Panel Moumt Adapters OWC-28E-240-M OWC-28E-240-M 26.5 40 0.3 20 50 WR-28 with UG599/U Flange 2.4 mm Male Details
Waveguide to Coax Panel Moumt Adapters OWC-42E-292-M-C OWC-42E-292-M-C 18 26.5 0.2 20 50 WR-42 with UG595/U Flange with O-Ring 2.92 mm (K) Male Details
Waveguide to Coax Panel Moumt Adapters OWC-42E-292-F-A OWC-42E-292-F-A 18 26.5 0.2 1.2:1 50 WR-42 Waveguide with UG-595/U Flange 2.92 mm (K) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-51E-292-F-A OWC-51E-292-F-A 15 22 0.2 20 50 WR-51 Waveguide with Standard Cover Flange 2.92 mm (K) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-34E-292-F-C OWC-34E-292-F-C 22 33 0.3 20 50 WR-34 Waveguide with Special Cover Flange, M2.5 Helicoil Holes 2.92 mm (K) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-51E-292-F-B OWC-51E-292-F-B 15 22 0.2 20 50 WR-51 Waveguide with Special Cover Flange, M2.5 Helicoil Holes 2.92 mm (K) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-42E-292-F-C OWC-42E-292-F-C 18 26.5 0.3 20 50 WR-42 with UG595/U Flange with O-Ring 2.92 mm (K) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-34E-292-F-B OWC-34E-292-F-B 22 33 0.3 20 50 WR-34 with UG-1530/U Flange with O-Ring 2.92 mm (K) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-75R-S-F OWC-75R-S-F 9.8 15 0.2 20 150 WR-75 Waveguide with Standard Flange SMA Female Connector Details
Waveguide to Coax Panel Moumt Adapters OWC-10E-100-F-A OWC-10E-100-F-A 75 110 0.8 16 10 WR-10 with UG387/U-M Flange 1.0 mm Female Details
Waveguide to Coax Panel Moumt Adapters OWC-34E-292-F-A OWC-34E-292-F-A 22 33 0.3 20 50 WR-34 Waveguide with UG-1530/U Flange 2.92 mm (K) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-10R-100-F OWC-10R-100-F 75 110 1.2 14 10 WR-10 with UG387/U-M Flange 1.0 mm Female Details
Waveguide to Coax Panel Moumt Adapters OWC-12R-100-F OWC-12R-100-F 60 90 1 14 10 WR-12 with UG387/U Flange 1.0 mm Female Details
Waveguide to Coax Panel Moumt Adapters OWC-22E-240-F-A OWC-22E-240-F-A 33 50 0.3 18 40 WR-22 with UG383/U Flange 2.4 mm (K) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-34R-292-M OWC-34R-292-M 22 33 0.3 20 50 WR-34 Waveguide with UG-1530/U Flange 2.92 mm (K) Male Details
Waveguide to Coax Panel Moumt Adapters OWC-22R-240-F-A OWC-22R-240-F-A 33 50 0.3 18 40 WR-22 with Non-Standard UG-599/U-M Square Flange 2.4 mm Female Details
Waveguide to Coax Panel Moumt Adapters OWC-34R-292-F OWC-34R-292-F 22 33 0.3 20 50 WR-34 Waveguide with UG-1530/U Flange 2.92 mm (K) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-22E-240-M-A OWC-22E-240-M-A 33 50 0.3 18 40 WR-22 with UG383/U Flange 2.4 mm (K) Male Details
Waveguide to Coax Panel Moumt Adapters OWC-42E-292-F-B OWC-42E-292-F-B 18 26.5 0.2 20 50 WR-42 Waveguide with Non-Standard UBR220 Flange 2.92 mm (K) Female Details
Waveguide to Coax Panel Moumt Adapters OWC-22R-240-M-B OWC-22R-240-M-B 33 50 0.3 18 40 WR-22 with Non-Standard UG-599/U-M Square Flange 2.4 mm Male Details
X
+
