Band Pass Filter From 100MHz (22.95～23.05GHz) With 2.92mm(K)-Female Connectors OBP-23000-100
Ocean Microwave band-pass filter (Ocean band-pass filter，abbreviation：abbreviation：OBP) is a filter that allows waves of specific frequencybandto pass through while rejecting other frequency bands.
The product name of this Ocean band-pass filter (OBP) is OBP-23000-100, its Center Frequency(F0) is 23GHz, its Pass Band Bandwidth is 100MHz (22.95～23.05GHz) ,its Pass Band Insertion Loss is ≤4.0dB, Pass Band VSWR is ≤1.3:1, and the Stop Band frequency is ≥40dB@DC～22.8GHz≥40dB@23.2～30GHz.
- Description
- Additional information
- Reviews (0)
Description
Ocean Microwave band-pass filter (Ocean band-pass filter，abbreviation：abbreviation：OBP) is a filter that allows waves of specific frequencybandto pass through while rejecting other frequency bands.
The product name of this Ocean band-pass filter (OBP) is OBP-23000-100, its Center Frequency(F0) is 23GHz, its Pass Band Bandwidth is 100MHz (22.95～23.05GHz) ,its Pass Band Insertion Loss is ≤4.0dB, Pass Band VSWR is ≤1.3:1, and the Stop Band frequency is ≥40dB@DC～22.8GHz≥40dB@23.2～30GHz.
Outline
Band Pass Filter Datasheet (Click to download)
Additional information
| Center Frequency (F0) (MHz) | |
|---|---|
| Min. Pass Band Frequency (MHz) | |
| Max. Pass Band Frequency (MHz) | |
| Pass Band Insertion Loss (dB) | |
| Stop Band Rejection | |
| Impedance (Ω) | |
| Power Handling (W) | |
| Connection Type |
