Mini sdi fiber converters long-distance transmission 12g sdi fiber Multifunctional fiber to sdi

Description

The 12G-SDI ultra-high-definition video optical transceiver is developed by our company and has independent intellectual property rights.Absorbing the advantages of similar products at home and abroad, and combining the actual needs of the market, the 4K60Hz ultra-high-definition video optical transceiver has been developed to achieve a delay-free, uncompressed, and high-quality signal extension of 10 kilometers.12G-SDI ultra-high-definition video optical transceiver has built-in serial clock recovery, signal equalization and line drive, input automatic detection signal 12G-SDI/6G-SDI/3G-SDI/HD-SDI/SDI/ASI, in line with SMPTEST2082-1 (12GUHD-SDI), ST2081-1 (6GUHDSDI), SMPTE424M, SMPTE292M, SMPTE259M, SMPTE297MSMPTE305M, SMPTE310M standard; 12G-SDI ultra-high-definition video optical transceiver, equipment power consumption is less than 1.5W, using USB port power supply, support USB power supply system, strong flexibility in use; 12G-SDI ultra-high-definition video optical transceiver circuit board adopts multi-layer design, the circuit is stable and reliable, and the anti-interference ability is strong; all components, including connectors, use products from internationally famous manufacturers, reliable quality; aluminum material shell design, corrosion resistance, outstanding thermal conductivity and conductive function
